Check Which Loops Were Vectorized using gcc or g++ Compiler

Loop vectorization is a powerful compiler optimization where repetitive operations (like array processing) are transformed into SIMD instructions. This allows the CPU to perform multiple operations in parallel using vector registers - massively boosting performance for math-heavy code. This tutorial explains how to check which loops were vectorized using gcc or g++ compiler.

Here's a simple function that divides each element in an array by a constant:

#include <stdio.h>

void divide(float *data, const size_t n, const float divisor) {
    for (size_t i = 0; i < n; ++i) {
        data[i] /= divisor;
    }
}

int main() {
    const int n = 18;
    float a[] = {
        0, 14, 28, 42, 56, 70, 84, 98, 112, 126, 140, 154, 168, 182, 196, 210, 224, 255
    };

    divide(a, n, 255);
    for (size_t i = 0; i < n; ++i) {
        printf("%f ", a[i]);
    }

    return 0;
}

This loop is simple and ideal for vectorization - no function calls inside the loop, no pointer aliasing, and regular memory access.

The -fopt-info-vec option tells to output a report of vectorized loops. To compile and generate the report, run the following command:

gcc -O3 -fopt-info-vec=vec.log main.c

• -O3 - enables aggressive optimizations (including vectorization).
• -fopt-info-vec=vec.log - writes vectorization messages to vec.log file.

After compiling, inspect the vec.log file:

main.c:4:26: optimized: loop vectorized using 16 byte vectors
main.c:4:26: optimized: loop vectorized using 16 byte vectors
main.c:5:17: optimized: basic block part vectorized using 16 byte vectors

This means:

• The loop in divide was successfully vectorized.
• Compiler used 16-byte wide vectors (i.e., 128-bit SIMD, typical of SSE).

The -fopt-info-vec also works with g++ when compiling C++ code.
