The fio (Flexible I/O Tester) is a benchmarking and testing tool designed to measure and analyze the performance of storage systems. It is widely used for testing the input/output performance of hard drives, SSDs, RAID arrays, and SANs.
This tutorial shows how to install fio benchmarking tool on Ubuntu 24.04.
Install fio
Update the package lists:
sudo apt update
Execute the following command to install fio:
sudo apt install -y fio
We can check fio version as follows:
fio --version
Testing fio
To use the fio
command, we can specify a set of options to define the workload for testing. For example, the command:
fio --name=fio_test --filename=/tmp/fio.tmp --rw=read --direct=1 --bs=1024k --size=102400k --iodepth=32 --ioengine=libaio --numjobs=1
The command runs a read performance test on a 100MiB file (--size=102400k
) using 1MiB block size (--bs=1024k
), 32 I/O operations at a time (--iodepth=32
), and Linux native asynchronous block level I/O (--ioengine=libaio
). The --direct=1
option ensures that the test bypasses the OS cache.
Here's an example of the output:
fio_test: (groupid=0, jobs=1): err= 0: pid=1940: Tue Sep 24 16:01:51 2024
read: IOPS=2173, BW=2174MiB/s (2280MB/s)(100MiB/46msec)
slat (usec): min=303, max=2570, avg=445.90, stdev=298.83
clat (usec): min=79, max=17273, avg=10176.86, stdev=3592.63
lat (usec): min=489, max=19554, avg=10622.76, stdev=3698.78
clat percentiles (usec):
| 1.00th=[ 80], 5.00th=[ 1926], 10.00th=[ 3654], 20.00th=[ 7373],
| 30.00th=[10945], 40.00th=[11207], 50.00th=[11207], 60.00th=[11338],
| 70.00th=[11600], 80.00th=[12256], 90.00th=[13304], 95.00th=[14484],
| 99.00th=[15139], 99.50th=[17171], 99.90th=[17171], 99.95th=[17171],
| 99.99th=[17171]
lat (usec) : 100=1.00%, 500=1.00%
lat (msec) : 2=3.00%, 4=5.00%, 10=17.00%, 20=73.00%
cpu : usr=0.00%, sys=100.00%, ctx=1, majf=0, minf=8203
IO depths : 1=1.0%, 2=2.0%, 4=4.0%, 8=8.0%, 16=16.0%, 32=69.0%, >=64=0.0%
submit : 0=0.0%, 4=100.0%, 8=0.0%, 16=0.0%, 32=0.0%, 64=0.0%, >=64=0.0%
complete : 0=0.0%, 4=98.6%, 8=0.0%, 16=0.0%, 32=1.4%, 64=0.0%, >=64=0.0%
issued rwts: total=100,0,0,0 short=0,0,0,0 dropped=0,0,0,0
latency : target=0, window=0, percentile=100.00%, depth=32
Run status group 0 (all jobs):
READ: bw=2174MiB/s (2280MB/s), 2174MiB/s-2174MiB/s (2280MB/s-2280MB/s), io=100MiB (105MB), run=46-46msec
Uninstall fio
If you want to completely uninstall fio and related dependencies, execute the following command:
sudo apt purge --autoremove -y fio
